BLM18KG102SN1D規格
| 形狀 |
SMD |
| 長度 |
1.6mm |
| 長度公差 |
±0.15mm |
| 寬度 |
0.8mm |
| 寬度公差 |
±0.15mm |
| 厚度 |
0.8mm |
| 厚度公差 |
±0.15mm |
| 工作溫度范圍 |
-55℃ to 125℃ |
| 質量(標準值) |
0.005g |
| 電路數目 |
1 |
| 額定電流(at 85℃) |
1A |
| 額定電流(at 125℃) |
800mA |
| 直流電阻 |
0.2Ω |
| 阻抗(at 100MHz) |
1000Ω |
| 阻抗(at 100MHz)公差 |
±25% |
| 尺寸代碼(單位為mm) |
1608 |
特點
The chip ferrite beads BLM series is designed to
function nearly as a resistor at noise frequencies,
which greatly reduces the possibility of resonance and
leaves signal wave forms undistorted.
BLM series is effective in circuits without stable
ground lines because BLM series does not need a
connection to ground.
The nickel barrier structure of the external
electrodes provides excellent solder heat resistance.
BLM_K series can be used in high current circuits
due to its low DC resistance. It can match power lines
to a maximum of 6A DC.
用途
包裝信息
| 包裝 |
規格 |
標準包裝數量 |
| B |
散裝袋 |
1000 |
| D |
180mm紙帶 |
4000 |
| J |
330mm紙帶 |
10000 |
